Assembly type
Self-assembly
Self-assembly
Self-assembly
-
-
Colour
Black
Black
Black
-
-
Degree of door perforation
-
-
> 65 %
-
-
Depth
[mm]
800
800
800
-
-
Door type
Single-leaf
Single-leaf
Single-leaf
-
-
Frame thickness
[mm]
1.5
1.2
1.5
-
-
Front door thickness
[mm]
5
5
1.2
-
-
Front door type
Temper glass
Temper glass
Perforation
-
-
Grounding Details
Back door, Frame, Front door
Back door, Frame, Front door
Back door, Frame, Front door
-
-
Height
[mm]
1461
1381
1461
-
-
Height without casters
[mm]
1354
1302
1354
-
-
ICT height
[U]
27
27
27
-
-
Included Accessories
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (4 fan's), Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Ventilation panel (4 fan's), Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (4 fan's), Wheels with brake
-
-
LCD panel
Yes
No
Yes
-
-
Maximum front door opening angle
[°]
215
215
215
-
-
Maximum static load
[kg]
1200
800
1200
-
-
Mounting rails thickness
[mm]
2
2
2
-
-
Number of vertical rails
4
4
4
-
-
Other elements sheet thickness
[mm]
1.5
1.2
1.2
-
-
RAL color
RAL9004
RAL9004
RAL9004
-
-
Rear door thickness
[mm]
1
1
1.2
-
-
Rear door type
Metal
Metal
Perforation
-
-
Side panel thickness
[mm]
1.2
1.2
1.2
-
-
Size
19"
19"
19"
-
-
Slot amount for fans
4
4
4
-
-
Standard
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
-
-
Thermostat
Yes
No
Yes
-
-
Type of cabinet
Free standing
Free standing
Free standing
-
-
Upper & lower panel thickness
[mm]
1.5
1.2
1.5
-
-
Weatherproof rating
IP20
IP20
IP20
-
-
Weight
[kg]
97.5
72.3
90
-
-
Width
[mm]
600
600
600
-
-
Working depth
[mm]
680
680
680
-
-
