Assembly type
Self-assembly
Self-assembly
Self-assembly
Self-assembly
-
Colour
Black
Black
Black
Black
-
Degree of door perforation
-
> 75%
-
-
-
Depth
[mm]
1200
1200
1200
1200
-
Door type
Single-leaf
Single-leaf
Single-leaf
Single-leaf
-
Frame thickness
[mm]
1.5
1.5
1.5
1.2
-
Front door thickness
[mm]
5
1.2
1.2
5
-
Front door type
Temper glass
Perforation
Temper glass
Temper glass
-
Grounding Details
Back door, Frame, Front door
Back door, Frame, Front door
Back door, Frame, Front door
Back door, Frame, Front door
-
Height
[mm]
2127.5
2127.5
2018
2047.5
-
Height without casters
[mm]
2020
2020
2121
1968.5
-
ICT height
[U]
42
42
42
42
-
Included Accessories
Front lock, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (6 fan's), Vertical cable management panel x2, Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (6 fan's), Vertical cable management panel x2, Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (6 fan's), Wheels with brake
Front lock, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (6 fan's), Vertical cable management panel x2, Wheels with brake
-
LCD panel
Yes
Yes
Yes
No
-
Maximum front door opening angle
[°]
215
215
215
215
-
Maximum static load
[kg]
1200
1200
1200
800
-
Mounting rails thickness
[mm]
2
2
2
2
-
Number of vertical rails
4
4
4
4
-
Other elements sheet thickness
[mm]
1.2
1.2
1.2
1.2
-
RAL color
RAL9004
RAL9004
RAL9004
RAL9004
-
Rear door thickness
[mm]
1
1.2
1.2
1.2
-
Rear door type
Metal
Perforation
Metal
Metal
-
Side panel thickness
[mm]
1.2
1.2
1.2
1
-
Size
19"
19"
19"
19"
-
Slot amount for fans
6
6
6
6
-
Standard
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
-
Thermostat
Yes
Yes
Yes
No
-
Type of cabinet
Free standing
Free standing
Free standing
Free standing
-
Upper & lower panel thickness
[mm]
1.5
1.5
1.5
1.2
-
Weatherproof rating
IP20
IP20
IP20
IP20
-
Weight
[kg]
156.5
139
134
155.5
-
Width
[mm]
800
800
600
800
-
Working depth
[mm]
1120
1120
1080
1120
-
