Assembly type
Self-assembly
Self-assembly
-
-
-
Colour
Black
Gray
-
-
-
Degree of door perforation
-
> 65 %
-
-
-
Depth
[mm]
1000
1000
-
-
-
Door type
Single-leaf
Single-leaf
-
-
-
Frame thickness
[mm]
1.5
1.5
-
-
-
Front door thickness
[mm]
5
1.2
-
-
-
Front door type
Temper glass
Perforation
-
-
-
Grounding Details
Back door, Frame, Front door
Back door, Frame, Front door
-
-
-
Height
[mm]
928
928
-
-
-
Height without casters
[mm]
821
821
-
-
-
ICT height
[U]
15
15
-
-
-
Included Accessories
Front lock, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (6 fan's), Vertical cable management panel x2, Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (6 fan's), Vertical cable management panel x2, Wheels with brake
-
-
-
LCD panel
Yes
Yes
-
-
-
Maximum front door opening angle
[°]
215
215
-
-
-
Maximum static load
[kg]
1200
1200
-
-
-
Mounting rails thickness
[mm]
2
2
-
-
-
Number of vertical rails
4
4
-
-
-
Other elements sheet thickness
[mm]
1.2
1.2
-
-
-
RAL color
RAL9004
RAL7035
-
-
-
Rear door thickness
[mm]
1
1.2
-
-
-
Rear door type
Metal
Perforation
-
-
-
Side panel thickness
[mm]
1.2
1.2
-
-
-
Size
19"
19"
-
-
-
Slot amount for fans
6
6
-
-
-
Standard
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
-
-
-
Thermostat
Yes
Yes
-
-
-
Type of cabinet
Free standing
Free standing
-
-
-
Upper & lower panel thickness
[mm]
1.5
1.5
-
-
-
Weatherproof rating
IP20
IP20
-
-
-
Weight
[kg]
78.5
73
-
-
-
Width
[mm]
800
800
-
-
-
Working depth
[mm]
860
810
-
-
-
