Assembly type
Self-assembly
Assembled
Self-assembly
Self-assembly
Self-assembly
Colour
Gray
Black
Black
Black
Black
Degree of door perforation
-
-
-
-
> 60%
Depth
[mm]
600
600
600
600
600
Door type
Single-leaf
Single-leaf
Single-leaf
Single-leaf
Single-leaf
Frame thickness
[mm]
1.5
1.2
1.5
1.2
1.2
Front door thickness
[mm]
5
5
5
5
1.2
Front door type
Temper glass
Temper glass
Temper glass
Temper glass
Perforation
Grounding Details
Back door, Frame, Front door
-
Back door, Frame, Front door
Back door, Frame, Front door
Back door, Frame, Front door
Height
[mm]
922
848
928
848
842
Height without casters
[mm]
819
-
821
769
769
ICT height
[U]
15
15
15
15
15
Included Accessories
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (2 fans), Wheels with brake
Front lock, Legs, Rear lock, Side locks, Ventilation panel (2 fans), Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (2 fans), Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Ventilation panel (2 fans), Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Wheels with brake
LCD panel
Yes
No
Yes
No
No
Maximum front door opening angle
[°]
180
215
215
215
210
Maximum static load
[kg]
1200
800
1200
800
800
Mounting depth range
[mm]
150 - 410
-
-
-
-
Mounting rails thickness
[mm]
2
2
2
2
2
Number of vertical rails
4
4
4
4
4
Other elements sheet thickness
[mm]
1.3
1.2
1.2
1.2
1.5
RAL color
RAL7035
RAL9004
RAL9004
RAL9004
RAL9004
Rear door thickness
[mm]
1
1
1
1
1.2
Rear door type
Metal
Metal
Metal
Metal
Perforation
Side panel thickness
[mm]
1.2
1.2
1.2
1.2
1.2
Size
19"
19"
19"
19"
19"
Slot amount for fans
2
2
2
2
2
Standard
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
Thermostat
Yes
No
Yes
No
No
Type of cabinet
Free standing
Free standing
Free standing
Free standing
Free standing
Upper & lower panel thickness
[mm]
1.5
1.2
1.5
1.2
1.2
Weatherproof rating
IP20
IP20
IP20
IP20
IP20
Weight
[kg]
60
45.5
49.5
45.5
43
Width
[mm]
600
600
600
600
600
Working depth
[mm]
410
520
480
480
480
