Assembly type
Self-assembly
Self-assembly
Self-assembly
Self-assembly
-
Colour
Gray
Black
Black
Black
-
Degree of door perforation
-
-
> 60%
-
-
Depth
[mm]
800
800
800
800
-
Door type
Single-leaf
Single-leaf
Single-leaf
Single-leaf
-
Frame thickness
[mm]
1.5
1.2
1.2
1.5
-
Front door thickness
[mm]
5
5
1.2
5
-
Front door type
Temper glass
Temper glass
Perforation
Temper glass
-
Grounding Details
Back door, Frame, Front door
Back door, Frame, Front door
Back door, Frame, Front door
Back door, Frame, Front door
-
Height
[mm]
922
848
848
928
-
Height without casters
[mm]
819
769
769
821
-
ICT height
[U]
15
15
15
15
-
Included Accessories
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (4 fan's), Wheels with brake
Front lock, Legs, M6 screws, Rear lock, Side locks, Ventilation panel (4 fan's), Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Ventilation panel (4 fan's), Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (4 fan's), Wheels with brake
-
LCD panel
Yes
No
No
Yes
-
Maximum front door opening angle
[°]
180
215
215
215
-
Maximum static load
[kg]
1200
800
800
1200
-
Mounting depth range
[mm]
150 - 690
-
-
-
-
Mounting rails thickness
[mm]
2
2
2
2
-
Number of vertical rails
4
4
4
4
-
Other elements sheet thickness
[mm]
1.3
1.2
1.2
1.2
-
RAL color
RAL7035
RAL9004
RAL9004
RAL9004
-
Rear door thickness
[mm]
1
1.2
1.2
1
-
Rear door type
Metal
Metal
Perforation
Metal
-
Side panel thickness
[mm]
1.2
1
1.2
1.2
-
Size
19"
19"
19"
19"
-
Slot amount for fans
4
4
4
4
-
Standard
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
-
Thermostat
Yes
No
No
Yes
-
Type of cabinet
Free standing
Free standing
Free standing
Free standing
-
Upper & lower panel thickness
[mm]
1.5
1.2
1.2
1.5
-
Weatherproof rating
IP20
IP20
IP20
IP20
-
Weight
[kg]
65
54.5
50
58
-
Width
[mm]
600
600
600
600
-
Working depth
[mm]
690
680
680
680
-
