Assembly type
Self-assembly
Self-assembly
-
-
-
Colour
Black
Black
-
-
-
Degree of door perforation
-
> 60%
-
-
-
Depth
[mm]
600
600
-
-
-
Door type
Single-leaf
Single-leaf
-
-
-
Frame thickness
[mm]
1.5
1.5
-
-
-
Front door thickness
[mm]
5
1.2
-
-
-
Front door type
Temper glass
Perforation
-
-
-
Grounding Details
Back door, Frame, Front door
Back door, Frame, Front door
-
-
-
Height
[mm]
1234
1239
-
-
-
Height without casters
[mm]
1132
1132
-
-
-
ICT height
[U]
22
22
-
-
-
Included Accessories
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (2 fans), Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (2 fans), Wheels with brake
-
-
-
LCD panel
Yes
Yes
-
-
-
Maximum front door opening angle
[°]
180
215
-
-
-
Maximum static load
[kg]
1200
1200
-
-
-
Mounting rails thickness
[mm]
2
2
-
-
-
Number of vertical rails
4
4
-
-
-
Other elements sheet thickness
[mm]
1.3
1.2
-
-
-
RAL color
RAL9004
RAL9004
-
-
-
Rear door thickness
[mm]
1.2
1.2
-
-
-
Rear door type
Metal
Perforation
-
-
-
Side panel thickness
[mm]
1.2
1.2
-
-
-
Size
19"
19"
-
-
-
Slot amount for fans
2
2
-
-
-
Standard
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
-
-
-
Thermostat
Yes
Yes
-
-
-
Type of cabinet
Free standing
Free standing
-
-
-
Upper & lower panel thickness
[mm]
1.5
1.5
-
-
-
Weatherproof rating
IP20
IP20
-
-
-
Weight
[kg]
73
71
-
-
-
Width
[mm]
600
600
-
-
-
Working depth
[mm]
480
480
-
-
-
