Assembly type
Self-assembly
Self-assembly
-
-
-
Colour
Gray
Gray
-
-
-
Depth
[mm]
450
350
-
-
-
Door type
Single-leaf
Single-leaf
-
-
-
Frame thickness
[mm]
1.2
1.2
-
-
-
Front door thickness
[mm]
5
5
-
-
-
Front door type
Temper glass
Temper glass
-
-
-
Grounding Details
Bottom panel, Front door
Bottom panel, Front door
-
-
-
Height
[mm]
512.35
500
-
-
-
ICT height
[U]
9
9
-
-
-
Included Accessories
Front lock, Grounding cable, M6 screws, Mounting bracket, Set of assembly elements, Side locks, User guide
Front lock, Grounding cable, M6 screws, Mounting bracket, User Manual
-
-
-
LCD panel
No
-
-
-
-
Maximum front door opening angle
[°]
-
220
-
-
-
Maximum static load
[kg]
60
60
-
-
-
Mounting rails thickness
[mm]
1.5
1.5
-
-
-
Number of vertical rails
4
4
-
-
-
Other elements sheet thickness
[mm]
1.2
1
-
-
-
RAL color
RAL7035
RAL7035
-
-
-
Rear door thickness
[mm]
1
-
-
-
-
Side panel thickness
[mm]
1
1
-
-
-
Size
19"
19"
-
-
-
Slot amount for fans
2
2
-
-
-
Standard
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
-
-
-
Thermostat
No
-
-
-
-
Type of cabinet
Wall mount
Wall mount
-
-
-
Upper & lower panel thickness
[mm]
1.2
1
-
-
-
Weatherproof rating
IP20
IP20
-
-
-
Weight
[kg]
18
13.8
-
-
-
Width
[mm]
600
540
-
-
-
Working depth
[mm]
392.5
305
-
-
-
