Assembly type
Self-assembly
Self-assembly
Self-assembly
Self-assembly
-
Colour
Black
Black
Black
Black
-
Degree of door perforation
> 65 %
> 65 %
-
-
-
Depth
[mm]
1200
1000
1000
800
-
Door type
Single-leaf
Single-leaf
Single-leaf
Single-leaf
-
Frame thickness
[mm]
1.2
1.5
1.5
1.5
-
Front door thickness
[mm]
1.2
1.2
5
5
-
Front door type
Perforation
Perforation
Temper glass
Temper glass
-
Grounding Details
Back door, Frame, Front door
Back door, Frame, Front door
Back door, Frame, Front door
Back door, Frame, Front door
-
Height
[mm]
1200
1239
1239
1239
-
Height without casters
[mm]
1128
1132
1132
1132
-
ICT height
[U]
22
22
22
22
-
Included Accessories
Front lock, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (6 fan's), Vertical cable management panel x2, Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (6 fan's), Vertical cable management panel x2, Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (6 fan's), Vertical cable management panel x2, Wheels with brake
Front lock, Grounding cable, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (4 fan's), Vertical cable management panel x2, Wheels with brake
-
LCD panel
No
Yes
Yes
Yes
-
Maximum front door opening angle
[°]
210
215
215
215
-
Maximum static load
[kg]
800
1200
1200
1200
-
Mounting rails thickness
[mm]
2
2
2
2
-
Number of horizontal rails
4
-
-
-
-
Number of vertical rails
4
4
4
4
-
Other elements sheet thickness
[mm]
1.2
1.2
1.2
1.5
-
RAL color
RAL9004
RAL9004
RAL9004
RAL9004
-
Rear door thickness
[mm]
1.2
1.2
1
1
-
Rear door type
Perforation
Perforation
Metal
Metal
-
Side panel thickness
[mm]
1.2
1.2
1.2
1.2
-
Size
-
19"
19"
19"
-
Slot amount for fans
6
6
6
4
-
Standard
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
-
Thermostat
No
Yes
Yes
Yes
-
Type of cabinet
-
Free standing
Free standing
Free standing
-
Upper & lower panel thickness
[mm]
1.2
1.5
1.5
1.5
-
Weatherproof rating
IP20
IP20
IP20
IP20
-
Weight
[kg]
115
104
109
85
-
Width
[mm]
800
800
800
800
-
Working depth
[mm]
1000
860
860
600
-
Working height
[mm]
978
-
-
-
-
