Assembly type
Self-assembly
Self-assembly
-
-
-
Colour
Black
Black
-
-
-
Depth
[mm]
450
600
-
-
-
Door type
Single-leaf
Single-leaf
-
-
-
Frame thickness
[mm]
1.2
1.2
-
-
-
Front door thickness
[mm]
5
5
-
-
-
Front door type
Temper glass
Temper glass
-
-
-
Grounding Details
Bottom panel, Front door
Bottom panel, Front door
-
-
-
Height
[mm]
907
907
-
-
-
ICT height
[U]
18
18
-
-
-
Included Accessories
Front lock, Grounding cable, M6 screws, Mounting bracket, Set of assembly elements, Side locks, User guide
Front lock, Grounding cable, M6 screws, Mounting bracket, Set of assembly elements, Side locks, User guide
-
-
-
LCD panel
No
No
-
-
-
Maximum static load
[kg]
60
60
-
-
-
Mounting rails thickness
[mm]
1.5
1.5
-
-
-
Number of vertical rails
4
4
-
-
-
Other elements sheet thickness
[mm]
1.2
1.2
-
-
-
RAL color
RAL9004
RAL9004
-
-
-
Rear door thickness
[mm]
1
1
-
-
-
Side panel thickness
[mm]
1
1
-
-
-
Size
19"
19"
-
-
-
Slot amount for fans
2
2
-
-
-
Standard
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
-
-
-
Thermostat
No
No
-
-
-
Type of cabinet
Wall mount
Wall mount
-
-
-
Upper & lower panel thickness
[mm]
1.2
1.2
-
-
-
Weatherproof rating
IP20
IP20
-
-
-
Weight
[kg]
27
30
-
-
-
Width
[mm]
600
600
-
-
-
Working depth
[mm]
392.5
529.5
-
-
-
