Bandwith
[Gbps]
20
4.8
-
-
-
Cooling
Passive, Vents
Passive
-
-
-
Environment humidity
[%]
10 - 90
10 - 90
-
-
-
Environment temperature
[°C]
-25 - 65
-25 - 65
-
-
-
Functions
Automatic MDI / MDI-X, Extend mode, Flow control, Intelligent PoE port disconnection function, MAC auto-learning, VLAN
Automatic MDI / MDI-X, Extend mode, Flow control, Intelligent PoE port disconnection function, MAC auto-learning, VLAN
-
-
-
Height
[mm]
44
44
-
-
-
Length
[mm]
152
124
-
-
-
MAC address table
4K
2K
-
-
-
Management
Unmanaged
Unmanaged
-
-
-
Material
Metal
Metal
-
-
-
Maxiumum network link speed
1 Gbps
1 Gbps
-
-
-
Network Link Type
Ethernet, Fiber
Ethernet, Fiber
-
-
-
Number of Ethernet ports
8
9
-
-
-
Number of POE ports
8
8
-
-
-
Number of fiber ports
2
1
-
-
-
Plug & Play
Yes
Yes
-
-
-
PoE power supply type
PoE, PoE+, PoE++
PoE, PoE+, PoE++
-
-
-
PoE standards
802.3af, 802.3at, 802.3bt
802.3af, 802.3at, 802.3bt
-
-
-
PoE support
Yes
Yes
-
-
-
Ports specification
2x 1000BASE-X SFP, 4x 1000BASE-T 802.3af/802.3at PoE+, 4x 1000BASE-T 802.3bt PoE++
1x 1000BASE-T, 1x 1000BASE-X SFP, 4x 100BASE-T 802.3af/802.3at PoE+, 4x 100BASE-T 802.3bt PoE++
-
-
-
Power Requirements
48~56V DC
48~56V DC
-
-
-
Software
No
No
-
-
-
Specialized
Industrial, Rack
Industrial, Rack
-
-
-
Surge protection
[kV]
6
6
-
-
-
Total budget for PoE
[W]
120
120
-
-
-
Type of casing
Din rail
Din rail, Rack
-
-
-
Weight
[kg]
0.53
0.53
-
-
-
Width
[mm]
124
152
-
-
-
Wired standards
IEEE 802.3af PoE, IEEE 802.3at PoE+, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3x (Flow-Control), IEEE 802.3z 1000Base-LX/SX
IEEE 802.3af PoE, IEEE 802.3at PoE+, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3x (Flow-Control), IEEE 802.3z 1000Base-LX/SX
-
-
-
Work signal
LED
LED
-
-
-
