Unmanaged Switches

SWITCH DSP1-0105 5X 100MB/S UNMANAGED FAST ETHERNET DESKTOP 5V

Manufacturer code: DSP1-0105
EAN: 5901969415674
Warranty: 24m
Number of Ethernet ports: 5
Ports specification: 5x 100BASE-TX
Maxiumum network link speed: 100 Mbps
Network Link Type: Ethernet

Product description

Lanberg DSP1-0105 is a small size unmanaged desktop switch, equipped with 5 Fast Ethernet ports. The device is small and handy and works on a plug-and-play basis. The switch provides switching function support for 5 RJ-45 10/100 Mbps ports along with automatic connection negotiation and MDI-MDIX support.

The Lanberg switch is ideal for home use, thanks to its very small size and the use of quiet cooling. The black color scheme and elegant slim housing, make the device fit into almost any interior. The device is suitable for office applications, including SOHO and SMB. The switch also provides adequate performance to meet user requirements in the switch segment.

The function of automatically recognizing and adapting to the type of network cable to be connected (straight or crossed), eliminates the need for only one type of cabling, as well as uplink ports, allowing to reduce unnecessary costs at the same time. The switch supports half-duplex and full-duplex modes for connections between devices. Instead, the flow control function allows you to control the flow of data thus avoiding port congestion in case one of the receiving devices is not able to receive enough of the received data.

Lanberg switch is a guarantee of a combination of high quality, automation and a number of functionalities, ensuring the operation of the device without redundant user intervention.

Features and functionalities:

- 5 RJ-45 10/100 Mbps ports with automatic connection negotiation,
- Plug-and-play - a device that does not require any additional configuration,
- Support for MDI/MDIX, MAC-learning, MAC-aging functionality,
- Data flow control function: back pressure @ half-duplex and IEEE 802.3x @ full duplex,
- Topology: Star,
- Protocol: CSMA/CD,
- MAC address table support: 1K,
- Switching bandwidth: 1.0 Gbps,
- Passive cooling for quiet switch operation,
- Wall mounting holes.

Interface:

- Power supply: external (AC: 100-240 V, 50/60 Hz, 0.3 A; DC: 5 V, 1.0 A).
- Current consumption: max. 2.15 W,
- LEDs indicating power supply operation: Power, LAN ports (Link/ACT),
- Dimensions: 82 x 52 x 22 mm.

Specification

Number of Ethernet ports 5
Ports specification 5x 100BASE-TX
Maxiumum network link speed 100 Mbps
Network Link Type Ethernet
Management Unmanaged
Type of casing Desktop
Chipset Realtek - RTL8305NB
PoE support No
Buffer 0.7 Mbit
Bandwith 1 Gbps
MAC address table 1K
Cooling Passive
Power Requirements 100~240V AC 0.3A, 5V DC 1A
Power consumption 2.15 W
Plug & Play Yes
Work signal LED
Wired standards IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3x (Flow-Control)
Functions Automatic MDI / MDI-X, Flow control, MAC auto-learning
Material Plastic
Software No
Length 82 mm
Width 52 mm
Height 22 mm
Weight 0.1 kg
Environment temperature 0 - 40 °C
Environment humidity 10 - 90 %

Number of Ethernet ports
5
Ports specification
5x 100BASE-TX
Maxiumum network link speed
100 Mbps
Network Link Type
Ethernet
Management
Unmanaged
Type of casing
Desktop
Chipset
Realtek - RTL8305NB
PoE support
No
Buffer
0.7 Mbit
Bandwith
1 Gbps
MAC address table
1K
Cooling
Passive
Power Requirements
100~240V AC 0.3A, 5V DC 1A
Power consumption
2.15 W
Plug & Play
Yes
Work signal
LED
Wired standards
IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3x (Flow-Control)
Functions
Automatic MDI / MDI-X, Flow control, MAC auto-learning
Material
Plastic
Software
No
Length
82 mm
Width
52 mm
Height
22 mm
Weight
0.1 kg
Environment temperature
0 - 40 °C
Environment humidity
10 - 90 %
