AWG
22 - 24
-
-
-
-
Bandwith
[Gbps]
-
12
12
-
-
Case material
Metal
-
-
-
-
Colour
Silver
-
-
-
-
Connector material
Phosphor bronze
-
-
-
-
Connectors
RJ-45
-
-
-
-
Cooling
-
Passive, Vents
Passive, Vents
-
-
Environment humidity
[%]
-
10 - 90
10 - 90
-
-
Environment temperature
[°C]
-10 - 60
-25 - 65
-25 - 65
-
-
Functions
-
Automatic MDI / MDI-X, Extend mode, Flow control, Intelligent PoE port disconnection function, MAC auto-learning, VLAN
Automatic MDI / MDI-X, Extend mode, Flow control, Intelligent PoE port disconnection function, MAC auto-learning, VLAN
-
-
Height
[mm]
19.6
30
30
-
-
ICT category
Cat. 6A
-
-
-
-
Keystone port height
[mm]
16.1
-
-
-
-
Keystone port width
[mm]
14.5
-
-
-
-
Length
[mm]
34
119
119
-
-
Life span of the socket
> 750 cycles
-
-
-
-
MAC address table
-
2K
2K
-
-
Management
-
Unmanaged
Unmanaged
-
-
Material
-
Metal
Metal
-
-
Maximum voltage
[V]
57
-
-
-
-
Maxiumum network link speed
-
100 Mbps, 1000 Mbps
1 Gbps
-
-
Network Link Type
-
Ethernet
Ethernet, Fiber
-
-
Number of Ethernet ports
-
5
4
-
-
Number of POE ports
-
4
4
-
-
Number of fiber ports
-
1
2
-
-
Plug & Play
-
Yes
Yes
-
-
PoE power supply type
PoE, PoE+, UPoE
PoE, PoE+, PoE++
PoE, PoE+, PoE++
-
-
PoE standards
-
802.3af, 802.3at, 802.3bt
802.3af, 802.3at, 802.3bt
-
-
PoE support
-
Yes
Yes
-
-
Ports specification
-
1x 100BASE-T 802.3bt PoE++, 3x 100BASE-T 802.3af/802.3at PoE+
1x 100BASE-T 802.3bt PoE++, 2x 1000BASE-X SFP, 3x 100BASE-T 802.3af/802.3at PoE+
-
-
Power Requirements
-
48~56V DC
48~56V DC
-
-
Shielding type
S/FTP
-
-
-
-
Software
-
No
No
-
-
Specialized
-
Industrial, Rack
Industrial, Rack
-
-
Surge protection
[kV]
-
6
6
-
-
Tool-free installation
Yes
-
-
-
-
Total budget for PoE
[W]
-
90
90
-
-
Type
Module
-
-
-
-
Type of casing
-
Din rail
Din rail
-
-
Weight
[kg]
-
0.4
0.53
-
-
Width
[mm]
14.5
94
94
-
-
Wired standards
-
IEEE 802.3af PoE, IEEE 802.3at PoE+, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3x (Flow-Control)
IEEE 802.3af PoE, IEEE 802.3at PoE+, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3x (Flow-Control), IEEE 802.3z 1000Base-LX/SX
-
-
Work signal
-
LED
LED
-
-
